When a file is deleted, the file system entry that maps the filename to the data on disk is removed. But the actual data often remains in storage, marked as “available” but not yet overwritten.
File carving is the technique of recovering these files based on their content — specifically, recognizable byte patterns at the start (and sometimes end) of different file types — without relying on the file system index.
How File Carving Works
Every common file type has a signature — a specific sequence of bytes that appears at the start of the file. These are called “magic bytes” or file headers. For example:
A file carver scans raw storage — byte by byte — looking for these signatures. When it finds one, it begins extracting data from that point for a defined length or until it finds a known footer (end signature).
Types of File Carving
Header-only carving: Identifies the file start but relies on file length or a heuristic to determine where the file ends. Works well for fixed-format files.
Header/footer carving: Identifies both the start and end of the file. More precise for file types with defined footers (JPEG uses `FF D9` as a footer). Fails when fragments from multiple files occur in the same area.
Fragment recovery / bifragment carving: Attempts to reconstruct files that are fragmented across non-contiguous sectors. Significantly more complex. Tools like Foremost and Scalpel don’t handle this well; specialized tools are needed.
File Carving Tools
Foremost: Classic open-source Linux tool. Command-line, defines file types in a configuration file. Fast but no fragmentation support.
Scalpel: Improved version of Foremost with better performance and configurability.
PhotoRec: Despite the name, recovers far more than photos — 480+ file types. Works on drives, memory cards, USB drives, and RAM images. Cross-platform, free.
Autopsy / The Sleuth Kit: Open-source forensic platform that includes file carving as one of its modules. Produces results in a GUI with case management.
Magnet AXIOM: Commercial forensic platform with built-in carving capabilities. Integrates carving results with other artifact analysis.
Bulk Extractor: Scans for patterns beyond standard files — email addresses, URLs, phone numbers, credit card numbers — from raw storage.
What File Carving Can and Can’t Do
Can recover:
Limitations:
File Carving in Practice
In a typical investigation, file carving runs against:
The output is reviewed by the examiner to identify relevant files. In a large drive carve, thousands of images may be recovered — many are web cache images, ad banners, and thumbnails. Triage tools sort and categorize carved output to reduce review time.
FAQ: File Carving
Q: If I overwrite deleted files with a “shredder” tool, can carving still recover them?
A: No. Shredder tools write random data to the sectors occupied by deleted files, destroying the original file content. Carving recovers data from unallocated space only when it hasn’t been overwritten.
Q: Can file carving work on SSDs?
A: Yes, but with lower success rates. SSDs implement TRIM, which signals the drive to zero sectors marked as free. When TRIM runs (which can happen immediately or in background), deleted file data is erased and carving finds nothing. HDDs don’t zero free space automatically, making them much better candidates for carving.
Q: Does file carving work on mobile devices?
A: Yes, when a physical image of the device’s NAND storage is acquired. Carving mobile device images follows the same principles as carving hard drives.
Q: How long does a typical forensic examination take?
A: Timelines vary based on data volume and case complexity. A single device may take one to three days; multi-device investigations can span weeks.
Q: What certifications should a digital forensics examiner hold?
A: Common certifications include EnCE, CFCE, CCE, and GCFE. Relevance depends on the examination type and the jurisdiction’s expectations.
Case Example
In a civil dispute, one party alleged digital evidence had been altered after a preservation obligation arose. The forensic examiner compared file system metadata against the litigation timeline and found several files modified after the preservation letter was received. A system cleanup utility had been run during the same period. The examiner documented the specific artifacts indicating post-preservation modifications, distinguishing between routine system operations and deliberate user actions, providing the court with a factual basis for evaluating the spoliation claim.
Practitioner Takeaways
- Verify forensic images with cryptographic hashing before analysis.
- Document every examination step for reproducibility.
- Cross-reference findings across multiple artifact types.
- Note tool versions used — behavior changes between versions affect reproducibility.
- Distinguish facts from inferences in your report.
